Product parameter

704WH

1408WH

1920WH

2636WH

Model

EA-BA-704WH

EA-BA-1408WH

EA-BA-1920WH

EA-BA-2636WH

Color

Black

Battery Type

LiFePo4

Battery Capacity

704WH

1408WH

1920WH

2636WH

Single Cell Voltage(V)

3.2

Single Cell Amp (Ah)

55Ah

55Ah

150Ah

206Ah

PACK Serial-Parallel Numbers

4s1p

4s2p

4s1p

4s1p

Rated Voltage

12.8V

Max Charging Current

55A

110A

150A

200A

Max Discharging Current

55A

110A

150A

200A

Ambient Temperature Range

-10~40℃

Storage Temperature

0-30℃

Storage Humidity

0-95%

Protection

Overcharge/Overdischarge/Overcurrent/Short-circuit/Over Temperature

IP Rate

IP54

Size[mm]L*W*H

L231*W145*H211

L332*W171 * H221

L502*W187* H242

L522 x W238 x H218

Net Weight

7.40KGS

11.0KGS

15.0KGS

19.0KGS
